Автомат горіння SATRONIC MMG 811.1 Mod 63 HONEYWELL

(Honeywell / Satronic control box MMG 811.1 Mod 63)

для керування розпалом європейських пальників.

Технічні характеристики:

• Supply voltage 220 / 240 V (-15... +10%), 50 Hz (50 - 60 Hz)
• AC frequency variations result in proportional timing deviations
• Fuse rating max. 10 A rapid, 6 A slow
• Power consumption 10 VA
• Max. current per output
• term. 3 2A, cos j 0.2
• term. 4, B 2A, cos j 0.4
• term. 5, 6, C 1A, cos j 0.4
• Total load 5A, cos j 0.4
• Amplifier sensitivity 1 mA
• Min. current from UV tube or ionisation probe 5 mA
• Flame detector cable max. 20 m cable length
• Air proving switch 1 terminal 4 A, 230 V
• Reset delay none
• Flame detector
  - Ionisation probe
  - Infra-red flicker detector IRD 1020
  - UV tube type UVZ 780 red markings
• installed radially or axially
• Infra red flare detector IRD 1020
• Weight incl. base 350 g
• Mounting attitude any
• Insulation standard IP 44
• Permissable ambient temp. -20° C... +60° C
• Classified acc. to EN 298 BTLLXN
